• SRA312-016

    16 channels real-time Linux-based network video recorder, support up to 8MP decoding resolution,
    4x 3.5” HDD Bay, H.265, pentaplex operations, plug and play, P2P, dual network interfaces, and remote management on various devices

Product Detail

  • Linux-embedded highly reliable standalone NVR with 3 year warranty
  • Plug-n-Play with integrated cameras, one click installation
  • Support P2P, one click for remote setup and monitoring
  • Third-party network cameras supported
  • Local configuration and display
  • 4x 3.5” HDD bays (each disk up to 12TB)
  • Up to 8 MP resolution recording
  • Up to 16 channels real-time live display, recording, and playback
  • H.265/H.264+ SDSTM (Smart Dynamic Streaming) Plus Technology: dual stream recording, 16 channels simultaneous playback without latency, reduces CPU usage and increases system stability
  • HDMI and VGA dual-monitor display, HMDI support to 4K resolution
  • Dual Ethernet ports, isolated local network environment for IP cameras
  • Easy export via USB or network, RTSP supported
  • Remote access through Web, CMS, mobile APP (Android & iOS)
  • Free DDNS service, IP address is not required for remote access
  • Free central management software (CMS Pro) up to 16 sites for multiple device management, upgradable to professional Expert Command Center System (ECCS100) up to 2000 channel management
NVR: SRA312 - 016
Operating System Embedded Linux
Operations Live, Recording, Playback, Backup & Remote access
Control Mode USB mouse, webpage, CMS
Video/ Audio Input
IP Camera Inputs 16 channels
Audio Mode 1 x RCA, 1 x RCA(Two ways Talk)
Audio Recording Yes
Video Compression H.265+/H.265/H.264+/H.264
Recording Resolution 8MP/6MP/5MP/4MP/3MP/1080p/720p/VGA/4CIF/2CIF/CIF
Bandwidth Input: 256Mbps; Output: 160Mbps
PTZ Support PTZ type: RS485 PTZ/ Network PTZ; Pan/Tilt/ Zoom Travel; Iris control; Focus/Auto Focus;
Presets 0~10; Presets Speed: Lowest/ Low/ Normal/ High/ Highest
Recording Mode Normal+ Event/ Event Only, Normal: Continuous/ Schedule, Event: Motion/ Alarm/ Video loss
Pre Recording 0~5 seconds
Post Recording 0~610 seconds
Display Resolution 8MP/6MP/5MP/4MP/3MP/1080p/720p/VGA/4CIF/2CIF/CIF
Display Mode Full Screen, PIP, 2x2, 3x3, 4x4
Decoding Capability 4-ch@8MP at 30fps or 16ch@2MP at 30fps
HDMI Output 4K(3840x2160)/30Hz, 2K(2560x1440/60Hz), 1920x1080/60Hz, 1600x1200/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1024x768/60Hz, 1280x720/60Hz
VGA Output 1920x1080/60Hz, 1600x1200/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1024x768/60Hz, 1280x720/60Hz
Frame Rate 5/8/10/13/15/20/25 fps/30fps
Bit Rate 512/ 1024/2048/ 3072/4096/5120/6144 Kbps
Remote View iPhone, iPad, Android phones, Android tablet, IE Explorer, CMS (CMS Pro & ECCS100)
Image Setting
Apply setting from camera Yes/No
Image Adjustment Brightness, Contrast, Saturation, Sharpness, Hue Adjust
Orientation Mirror, Flip
Playback & Backup
Playback Capability 16 channels simultaneous playback without latency
Playback Control play, pause, stop, forward, rewind, fast forward, fast rewind
Search Control by date, time, events, channel
Export Through USB /Webpage / CMS
Storage 4x 3.5” HDD bays (each HDD up to 12TB)
Alarm I/O 16 x alarm-in, 4 x alarm-out
Event Trigger Alarm Detection, Motion Detection, Tampering Alarm, Object Detection, Intrusion Detection, Video Loss Detection
Object& Intrusion Detection (Line) Object Counting , Line Intrusion , Zone Object-Counting, Zone Intrusion
Alarm Detection Disk Full, Disk Error, No Disk, Network Disconnect, Illegal Login, Disk Over Temperature, Fan Fall, Power Loss
IP Conflict
Event Actions Buzzer
Spot on Main Monitor
Notification via email SMTP, SSL, STARTTLS
Send to Alarm Server
File upload via FTP, Network Storage and email
Alarm output port
Push to Mobile
Watermark Yes
User Guest (Live, OSD, Zoom)/ Operator (all function except for configuration)/ Admin (all function)
Management of user’s camera access (limit user’s access to any camera)
ONVIF Yes; Profile S
Ethernet Dual Gigabyte Ethernet 1 x 10/100/1000Mbps (WAN), 1 x 10/100/1000Mbps (LAN)
Language English, Thai, Chinese
I/O 3 x USB port , 1 x RS485 (Support Pelco D, Pelco P)
Power DC 12V, 90W, Switching power supply, 100-240VAC
Dimension 420(W)x 65(H)x305(D) mm ± 5mm / 1.3”(W)x 0.2”(H)x 1.0”(D) ± 0.01”
Operating Temperature 0°C to 50°C / 32°F to 122°F
